Pond footings help

Discussion in 'Garden Projects and DIY' started by bigbore, Jul 22, 2015.

  1. bigbore

    bigbore Super Gardener

    Joined:
    May 20, 2013
    Messages:
    390
    Gender:
    Male
    Ratings:
    +778
    If I want to build a collar like below Do I need to put down some footings or can I build straight on the soil?

    [​IMG]

  2. bigbore

    bigbore Super Gardener

    Joined:
    May 20, 2013
    Messages:
    390
    Gender:
    Male
    Ratings:
    +778
    The ground will be built up around it after like below

    [​IMG]

  3. pete

    pete Growing a bit of this and a bit of that....

    Joined:
    Jan 9, 2005
    Messages:
    51,787
    Gender:
    Male
    Occupation:
    Retired
    Location:
    Mid Kent
    Ratings:
    +96,315
    Personally I'd say you need atleast four inches of concrete, possibly more under the dwarf wall.
    Tend to think if it was me I'd add some reinforcing bar as well.

    • Like Like x 1
    • Agree Agree x 1
    • vibrating_cake

      vibrating_cake Gardener

      Joined:
      Sep 18, 2014
      Messages:
      181
      Gender:
      Male
      Occupation:
      Actually Called Neil
      Location:
      That there Yorkshire!
      Ratings:
      +272
      I'd put footings down if only to give you a flat level to lay the brick from, if it's on soil, in soil it'll move around a lot and crack and break up with varying moisture levels in the soil around it.
      just think when you leave a large pot to go bone dry, the soil shrinks so much it peels away from the edge and leaves a gap.
      same for the pond, the outside soil shrinks and is no longer holding the wall plus the pond waters weight up, the wall will tend to bow out opening up the mortar.
      with footings it'll have more chance of staying put and in one piece

    • Bumbalina

      Bumbalina My name is Bumbalina and I am a garden-a-holic

      Joined:
      Jul 14, 2015
      Messages:
      47
      Gender:
      Female
      Occupation:
      Carer for my nan
      Location:
      Charfield, South Gloucestershire
      Ratings:
      +46
      hi, i imagine that you have already got started on this but i did something very similar with my pond. Yes i would (and did) put footings down, as suggested 4 inches should be enough. Also, i did a twin wall, so an inside layer of bricks as well just to make sure. I then filled it with cement to the top layer of breeze blocks, topped it off with house bricks, filled with soil and sowed grass.
